GB100 PLUS is the best, cheapest and fastest solutions to manage, control,
measure and create Low-Flow and Micro Gas Mixtures or Dilutions.
We produce advanced, certified, interconnected, and trusted technologies dedicated to Laboratories.
This revolutionary instrument currently helps many of the most relevant universities and companies around the globe. Bring forward your experiments, calibrations and manage gas mixtures with a single click!
N2, O2, CO2, CH4, Air, He, H2 (additional gases supported on request)
• Accuracy: (for each channel) N2, 20 ºC, 101.325 kPa (1 atm):
5-100% FS: 1% of SP
< 5% FS: 0,2% of FS
• Repeatability: 0,10% of reading
• Response time: (for each channel) 100 ms
• Power Supply: In Bundle
• Operation Pressure: Max 3 bar
• Working Temperature: 0 – 50 °C
• Mass Flow Rates: (for each channel) 0 – 500 mL/min
• Total Mixture Flow Rate: Up to 3 L/min
• Gases: N2, O2, CO2, CH4, Air, He, H2 (additional gases supported on request)
• Compatibility: Profibus, Modbus, Matlab Simulink, Python
• Communication: USB PC Interface RS485 with open proprietary protocol.
• Fittings:Swagelok NPT or Push-in fittings for 6-4mm tubes. Other on request
• Inlet Gas Channel: Up to 6 Inputs
• Outlet Gas Channel: 1 Output of mixed gases
• User Interface: Gas mixing software. Touch Display.
• Certifications: CE, TUV, cTUVUS, Made in Italy
The .FREE Version of the software manager is an integrated component of the instrument. You can easily manage all the functions and regulate the flows. You can also save and load the mixtures providing a full automation.
